JL Audio 2 Ch. Class D Full-Range Marine Amplifier, 200 W - M200/2
| $649.95 |
2-Channel Class D Marine Full-Range Amplifier, 100 W x 2 @ 2 Ω / 75 W x 2 @ 4 Ω - 14.4V
This tiny amplifier packs a serious full-range punch, delivering a staggering 100 watts per channel into 2 Ω (14.4V, 1% THD). The breakthrough that makes this much power possible in such a small chassis is our NexD™ ultra-high-speed switching design, which allows for full bandwidth Class D operation with extremely low distortion and outstanding efficiency.
The M200/2 includes a 12 dB / octave filter which can be configured as a low-pass or high-pass filter and offers continuously variable cutoff frequency selection from 50-500 Hz. With the addition of an HD-RLC remote level control (sold separately), the amplifier's level can be controlled from a remote location.
This marine amplifier features white and gray powder-coat finishes, a gasketed cover for the controls and stainless steel hardware for durability in the marine environment.
Specification
Rated Continuous (RMS) Power @ 14.4 V
- @ 4 Ω : 75 W RMS x 2
- @ 2 Ω : 100 W RMS x 2
- Bridged @ 4Ω : 200 W RMS x 1
Rated Continuous (RMS) Power @ 12.5 V
- @ 4 Ω : 60 W RMS x 2
- @ 2 Ω : 90 W RMS x 2
- Bridged @ 4Ω : 180 W RMS x 1
General Specifications
- Frequency Response : 12 Hz - 22 kHz (+0, -1dB)
- S/N Ratio, referred to highest rated power : >104 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- S/N Ratio, referred to 1 W : >84 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- Damping Factor @ 4 Ω : >150 / 50 Hz
- Damping Factor @ 2 Ω : >75 / 50 Hz
- THD+N @ Rated Power : <1% @ 2 Ω per Ch.
- Input Voltage Range @ RCA Inputs : 100 mV - 4 V RMS
- Min.Copper Power / Ground Wire Gauge : 8 AWG wire
- Fuse Rating : 20 A (AFS, AGU or MaxiFuse™)
Signal Processing
- Filter Mode(s) : Low-Pass or High-Pass
- Filter Slope(s) : 12 dB/octave
- Filter Frequency Range : 50 Hz - 500 Hz
- Detented, Calibrated Filter Freq. Potentiometers : Yes
- Filter Defeat Function : Yes
- Remote Level Control : Optional (HD-RLC)
- Remote Level Modes : N/A
- Channel Input Mode Switch : N/A
- Pass-Through Preamp Output : Buffered
- Source Channel Selection for PreOuts : N/A
Physical Specifications
- Height (H) : 2.05 in / 52 mm
- Width (W) : 6.85 in / 174 mm
- Depth (D) : 7.09 in / 180 mm
- Net Weight : 3.75 lb / 1.70 kg
