Kenwood CD Receiver With Bluetooth - KDC-BT282U
WAS $199.00 |
$178.00 |
- 204 Segment 1 Line Text Display
- Bluetooth Direct Access Button
- Blue/White Color Illumination
- 13Band EQ & DTA
- Front USB & AUX IN
- 1 Preout 2.5V
Music Mix
Up to 5 Bluetooth® devices can be paired to the receiver at the same time. You can enjoy audio streaming just by switching the devices with your friends or family.
Dual Phone Connection
While you are connected through Bluetooth, with a touch of a button you can switch between two phones.
Remote App
A smartphone application can control most basic functions of the receiver over the Bluetooth connection of the paired phone (iPhone or Android).
Wireless Music Browsing (AVRCP 1.5 / 1.6)
Search and select songs from your music collection through a Bluetooth connection.
Graphic EQ / Digital Time Alignment
13-Band equalizer and DTA gives optimal tuning enhancements for listeners.
Drive EQ
Boosts specific frequencies in the audio signal to overcome the negative impact of road noise.
FLAC Supported
Compatible with various audio file formats from FLAC and WAV, to MP3, WMA and AAC.
Android Rapid Charge
Rapidly charge your compatible Android smartphone with the USB port, up to a maximum of 1.5A.
Smartphone Connectivity
By connecting your smartphone and receiver wirelessly, your driving time will be more fun and convenient.
Equipped with the Intuitive KENWOOD Music Mix
Up to 5 Bluetooth® devices can be connected to the receiver at the same time, allowing you to take turns streaming music with your friends and family.
Dual Phone Connection
While you are connected through Bluetooth, with a touch of a button you can switch between two phones.
Control the Receiver from Your Smartphone with the KENWOOD Remote App
A smartphone application can control most basic functions of the receiver over the Bluetooth connection of the paired phone (iPhone or Android).
Designed for Ease of Use
Direct Bluetooth keys allow you to access quickly to answering to and making a call, and entering Bluetooth Audio source.
And Vertical Alignment LCD display secures higher visibility during day-time drive.
Front USB and AUX Input Compatible with a Variety of USB-Enabled Devices
Easy front panel connection for your compatible USB- enabled devices. These include Mass Storage Class devices like iPods, smartphones, and USB flash drives. The USB input will allow you to charge and control the music playback of your select devices.
The Best Audio Experience
Sound quality enthusiasts will love the playback support of various types of music formats, including compatibility with FLAC files. Simple touch screen sound customization is also available with its built-in 13-Band EQ and Digital Time Alignment.
Playable USB Files
Compatible with a broad range of audio file formats from FLAC and WAV, to MP3, WMA and AAC.
13-Band EQ / Digital Time Alignment
13-Band equalizer and DTA gives optimal tuning enhancements for the listener.
Digital Time Alignment
Sound coming from a variety of speakers located within your car are time aligned to arrive at your ear at exactly the same time.
Drive Equalizer
Drive EQ boosts specific frequencies in the audio signal to compensate the negative impact of road noise.
System EXPANSION Ready
The KENWOOD receiver has RCA outputs to expand the system to connect to an additional amplifier or powered subwoofer.
Additional Features
Learn about exciting product features and highlights.
Spanish and French Text Display
On-screen display menu now available in Spanish and French.
FM | |
---|---|
Frequency Range(MHz) (Frequency step) | 87.9MHz to 107.9MHz (200kHz) |
Usable Sensitivity S/N:30dB | 8.2dBf (0.71μV/75Ω) |
Quieting Sensitivity DIN S/N:46dB | 17.2dBf (2.0μV/75Ω) |
Frequency Response (±3.0dB) | 30Hz to 15kHz |
S/N(dB) | 64.0dB(MONO) |
Stereo Separation | 40dB(1kHz) |
MW (AM) | |
Frequency Range(kHz) (Frequency step) | 530kHz to 1700kHz (10kHz) |
Usable Sensitivity (S/N 20dB) | 29dBμ (28.2μV) |
CD | |
Laser Diode | GaAlAs |
Digital Filter(D/A) | 8 Times OverSampling |
Spindle Speed | 500 to 200rpm (CLV) |
Wow & Flutter | Below Measurable Limit |
Frequency Response | 20Hz to 20kHz(±1dB) |
Total Harmonic Distortion | 0.02%(1kHz) |
S/N Ratio (dB) | 94dB(1kHz) |
Dynamic Range | 91dB |
Channel Separation | 86dB |
MP3 Decode | Compliant with MPEG-1/2 Audio Layer-3 |
WMA Decode | Compliant with WINDOWS MEDIA AUDIO |
AAC Decode | AAC-LC ".aac" files |
WAV Decode | - |
Preout Level(mV)/Load | |
-Unbalanced | 2500mV/10kΩ |
Preout Impedance(Ω) | |
Preout Impedance(Ω) | =<600Ω |
Speaker Impedance(Ω) | |
Speaker Impedance(Ω) | 4 to 8Ω |
USB I/F | |
USB | USB 1.1 / 2.0 High Speed |
File System | FAT12 / 16 / 32 |
Maximum Supply current | DC5V(DC logo) 1.5A |
Frequency Response | 20Hz to 20kHz(±1dB) |
S/N Ratio (dB) | 98dB(1kHz) |
Dynamic Range | 94dB |
Channel Separation | 91dB |
MP3 Decode | Compliant with MPEG-1/2 Audio Layer-3 |
WMA Decode | Compliant with Windows Media Audio |
AAC Decode | AAC-LC ".aac",".m4a" files |
WAV Decode | Linear-PCM |
FLAC Decode | FLAC file (Up to 24bit/96kHz) |
AUX Input | |
Frequency Response | 20Hz to 20kHz ±3dB |
Input Maximum Voltage | 1000mV |
Input Impedance | 30kΩ |
AMP | |
PWR(MAX) | 50Wx4 |
Full Bandwidth Power (at less than 1%THD) | 22Wx4 |
TONE | |
Band1 | 62.5Hz ±9dB |
Band2 | 100Hz ±9dB |
Band3 | 160Hz ±9dB |
Band4 | 250Hz ±9dB |
Band5 | 400Hz ±9dB |
Band6 | 630Hz ±9dB |
Band7 | 1kHz ±9dB |
Band8 | 1.6kHz ±9dB |
Band9 | 2.5kHz ±9dB |
Band10 | 4kHz ±9dB |
Band11 | 6.3kHz ±9dB |
Band12 | 10kHz ±9dB |
Band13 | 16kHz ±9dB |
Bluetooth | |
Version | Bluetooth 4.2 |
Frequency Range | 2.402 to 2.480GHz |
RF Output Power (E.I.R.P.) | +4dBm (MAX), Power Class 2 |
Maximum Communication range | Line of sight approx.10m(32.8ft) |
Profile | HFP 1.7.1 (Hands Free Profile) |
Profile | SPP (Serial Port Profile) |
Profile | PBAP (Phonebook Access Profile) |
Profile | A2DP (Advanced Audio Distribution Profile) |
Profile | AVRCP 1.6.1 (Audio/Video Remote Control Profile) |
GENE | |
Operating voltage | 12V DC car battery |
Installation Size(W) (H) (D) | 182(mm) 7-3/16(in), 53(mm) 2-1/16(in), 155.5(mm) 6-1/8(in) |
Net Weight | 1.2(kg) 2.7(lbs), (Trim plate and Mounting sleeve: Included) |
