Kenwood Dual Din Sized Digital Media Receiver with Bluetooth - DPX305MBT
| WAS $199.00 |
|
$178.00 |
- 420 Segment 3 Line Text Display
- Amazon Alexa Ready
- Bluetooth Direct Access Button
- Short Chassis
- 13Band EQ & Digital Time Alignment
- Variable Color Illumination
- 3 Preouts 2.5V
Music Mix
Up to 5 Bluetooth® devices can be paired to the receiver at the same time. You can enjoy audio streaming just by switching the devices with your friends or family.
Dual Phone Connection
While you are connected through Bluetooth, with a touch of a button you can switch between two phones.
Remote App
A smartphone application can control most basic functions of the receiver over the Bluetooth connection of the paired phone (iPhone or Android).
Graphic EQ / Digital Time Alignment
13-Band equalizer and DTA gives optimal tuning enhancements for listeners.
Drive EQ
Boosts specific frequencies in the audio signal to overcome the negative impact of road noise.
Variable Color Illumination
Bright variable color LEDs can be adjusted to match any color dash lighting.
Short Chassis
With receivers shorter in depth than any of our previous models, installation is made easier in a wider range of cars.
Amazon Alexa Compatible
With Alexa on your KENWOOD Receivers, you can use your voice to control your music and much more. Using Alexa is as easy as asking a question. Just ask and Alexa can play your favorite song, skip to the next track, change the volume, read you the news and more.
Using Alexa on the KENWOOD Receiver is simple and hands-free, just ask and Alexa will respond instantly, or press the Amazon Alexa key on the KENWOOD receiver, you can easily activate Alexa and get voice control.
Streaming Music
Listen to popular music applications and music stored on your device with basic audio controls.
Equipped with the Intuitive KENWOOD Music Mix
Up to 5 Bluetooth® devices can be connected to the receiver at the same time, allowing you to take turns streaming music with your friends and family.
Dual Phone Connection
While you are connected through Bluetooth, with a touch of a button you can switch between two phones.
A smartphone application can control most basic functions of the receiver over the Bluetooth connection of the paired phone (iPhone or Android).
Front USB and AUX Input Compatible with a Variety of USB-Enabled Devices
Easy front panel connection for your compatible USB- enabled devices. These include Mass Storage Class devices like iPods, smartphones, and USB flash drives. The USB input will allow you to charge and control the music playback of your select devices.
The Best Audio Experience
13-Band EQ / Digital Time Alignment
13-Band equalizer and DTA gives optimal tuning enhancements for the listener.
Playable USB Files
Compatible with a broad range of audio file formats from FLAC and WAV, to MP3, WMA and AAC.
Digital Time Alignment
Sound coming from a variety of speakers located within your car are time aligned to arrive at your ear at exactly the same time.
Drive Equalizer
Drive EQ boosts specific frequencies in the audio signal to compensate the negative impact of road noise.
System EXPANSION Ready
The KENWOOD receiver has RCA outputs to expand the system to connect to an additional amplifier or powered subwoofer.
Additional Features
Match Your Mood with Variable Color Illumination
Bright variable color LEDs can be adjusted to match any color dash lighting.
Adjustable 3-Zone Variable Color Illumination
You can adjust the front panel illumination into 3 separate color zones.
Short Chassis for Easier Installation than Ever Before
With 2DIN audio receivers shorter in depth, installation is made easier in a wider range of cars.
SiriusXM Radio Ready
Access additional music, sports and entertainment content on the go with SiriusXM Radio.
(Optional SiriusXM tuner required, sold separately)
Spanish and French Text Display
On-screen display menu now available in Spanish and French.
| Speaker Impedance(Ω) | |
|---|---|
| Speaker Impedance(Ω) | 4 to 8Ω |
| USB I/F | |
| MP3 Decode | Compliant with MPEG-1/2 Audio Layer-3 |
| Channel Separation | 90dB |
| Dynamic Range | 93dB |
| S/N Ratio (dB) | 98dB(1kHz) |
| Frequency Response | 20Hz to 20kHz(±1dB) |
| Maximum Supply current | DC5V(DC logo) 1.5A |
| File System | FAT12 / 16 / 32 |
| USB | USB 1.1 / 2.0 High Speed |
| AUXInput | |
| Frequency Response | 20Hz to 20kHz ±3dB |
| Input Maximum Voltage | 1,000mV |
| TONE | |
| Band3 | 160Hz ±9dB |
| Band2 | 100Hz ±9dB |
| Band1 | 62.5Hz ±9dB |
| AMP | |
| Full Bandwidth Power(at less than 1%THD) | 22Wx4 |
| AUXInput | |
| Input Impedance | 30kΩ |
| GENE | |
| Operating voltage | 12V DC car battery |
| Bluetooth | |
| Profile | AVRCP 1.6.1 (Audio/Video Remote Control Profile) |
| Profile | A2DP (Advanced Audio Distribution Profile) |
| Profile | PBAP (Phonebook Access Profile) |
| Profile | SPP (Serial Port Profile) |
| Profile | HFP 1.7.1 (Hands Free Profile) |
| Maximum Communication range | Line of sight approx.10m(32.8ft) |
| RF Output Power (E.I.R.P.) | +4dBm (MAX), Power Class 2 |
| Frequency Range | 2.402 to 2.480GHz |
| Version | Bluetooth 4.2 |
| TONE | |
| Band13 | 16kHz ±9dB |
| Band12 | 10kHz ±9dB |
| Band11 | 6.3kHz ±9dB |
| Band10 | 4kHz ±9dB |
| Band9 | 2.5kHz ±9dB |
| Band8 | 1.6kHz ±9dB |
| Band7 | 1kHz ±9dB |
| Band6 | 630Hz ±9dB |
| Band4 | 250Hz ±9dB |
| Band5 | 400Hz ±9dB |
| USB I/F | |
| WMA Decode | Compliant with Windows Media Audio |
| Preout Impedance(Ω) | |
| Preout Impedance(Ω) | =<600Ω |
| Preout Level(mV)/Load | |
| -Unbalanced | 2,500mV/10kΩ |
| MW(AM) | |
| Usable Sensitivity(S/N 20dB) | 29dBμ (28.2μV) |
| Frequency Range(kHz)(Frequency step) | 530kHz to 1700kHz(10kHz) |
| FM | |
| Stereo Separation | 40dB(1kHz) |
| Frequency Response(±3.0dB) | 30Hz to 15kHz |
| S/N(dB) | 64.0dB(MONO) |
| Quieting SensitivityDIN S/N:46dB | 17.2dBf(2.0μV/75Ω） |
| Usable SensitivityS/N:30dB | 8.2dBf(0.71μV/75Ω） |
| Frequency Range(MHz)(Frequency step) | 87.9MHz to 107.9MHz(200kHz) |
| USB I/F | |
| AAC Decode | AAC-LC ".aac",".m4a" files |
| WAV Decode | Linear-PCM |
| FLAC Decode | FLAC file (Up to 24bit/96kHz) |
| AMP | |
| Maximum Power | 50Wx4 |
| GENE | |
| Installation Size(W) (H) (D) | 178(mm) 7(in), 100(mm) 3-15/16(in), 100(mm) 3-15/16(in) |
| Net Weight | 0.8(kg) 1.8(lbs) |
